Mendota FV36 - Specific Component Details

59
FV36 85-03-01014
Convection Blowers: The convection blowers are mounted on the firebox’s rear wall. To access the
convection blowers, remove the burners and airbox from the fireplace.
Accent Light: The accent light is mounted in the firebox top center area. The accent light wire harness is run
from the light housing to the left side and then down to the ignition control module.
Convection Blowers
Accent Light
HA-110-00002
LEFT BLOWER ASSEMBLY
15-02-00130
EBM BLOWER LH, ROTATED
HA-110-00003
RIGHT BLO WER ASSEMBLY
15-02-00129
EBM BLOWER, RH ROTATED
65-02-01032
FV36 BLOW ER G ASKET
HA-77-00357
HA-88-00168
HA-58-04606
10-11-00020
10-11-00025
LIGHT C O VER CLIP
LENS RETAINER BRACKET W ITH GASKET
ACCENT LIGHT HOUSING
LIGHT BULB, G9 XENON, 25W
ACCENT LIGHT LENS-2016
