200/225/250/275 VERADO 4-STROKE
Page 8 / 51 90-10238051
5. Refer to Determining Recommended Outboard Mounting Height, and install outboard
to the nearest recommended mounting height.
a - Lifting eye b - Mounting bolts
Lifting Eye 91-895343T01
6. Fasten outboard with mounting hardware provided. Refer to Fastening Outboard.
Fastening Outboard
1. Place lower mounting bolts into mounting slots before placing outboard on transom.
2. Refer to Determining Recommended Outboard Mounting Height, and install outboard
to the nearest recommended mounting height.
3. Fasten outboard with the stainless steel bolts, nylon insert locknuts and flat washers
as shown.
