Mercury 225 VERADO Installation Manual

200/225/250/275 VERADO 4-STROKE
Page 46 / 51 90-10238051
Tube Ref No. Description Where Used Part No.
94
Anti-Corrosion Grease Propeller shaft splines 92-802867A1
95
2-4-C Marine Lubricant with
Teflon
Propeller shaft splines 92-802859A1
2. Flo-Torq II Drive Propellers - Install forward thrust hub, replaceable drive sleeve,
propeller, thrust hub, propeller nut retainer, and propeller nut onto the shaft.
b
c
a
d
f
e
ob00421
a - Propeller nut
b - Propeller nut retainer
c - Thrust hub
d - Propeller
e - Replaceable drive sleeve
f - Forward thrust hub
3. Place a block of wood between gearcase and propeller and torque nut to specification.
Description Nm lb. in. lb. ft.
Nut 75 55
4. Secure propeller nut by bending three of the tabs into the thrust hub grooves.
ob00422

Mercury 225 VERADO Specifications

General

Horsepower	225 HP
Full Throttle RPM Range	5800-6400 RPM
Steering	Electro-hydraulic power steering
Dry Weight	635 lbs / 288 kg
Cylinders	6
Gear Ratio	1.85:1
Alternator Output	70 amp (882 watt)
Shaft Length	20", 25"
Starting System	Electric
Warranty	3 years
Fuel Induction System	Electronic Fuel Injection (EFI)
