200/225/250/275 VERADO 4-STROKE
Page 8 / 51 90-10238051
5. Refer to Determining Recommended Outboard Mounting Height, and install outboard
to the nearest recommended mounting height.
3731
a
b
a - Lifting eye b - Mounting bolts
Lifting Eye 91-895343T01
6. Fasten outboard with mounting hardware provided. Refer to Fastening Outboard.
Fastening Outboard
1. Place lower mounting bolts into mounting slots before placing outboard on transom.
2. Refer to Determining Recommended Outboard Mounting Height, and install outboard
to the nearest recommended mounting height.
3. Fasten outboard with the stainless steel bolts, nylon insert locknuts and flat washers
as shown.

Table of Contents

Other manuals for Mercury 225 VERADO

Preview: Manual
Manual145 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercury 225 VERADO and is the answer not in the manual?

Mercury 225 VERADO Specifications

General IconGeneral
Horsepower225 HP
Full Throttle RPM Range5800-6400 RPM
SteeringElectro-hydraulic power steering
Dry Weight635 lbs / 288 kg
Cylinders6
Gear Ratio1.85:1
Alternator Output70 amp (882 watt)
Shaft Length20", 25"
Starting SystemElectric
Warranty3 years
Fuel Induction SystemElectronic Fuel Injection (EFI)
