Mercury 60 4-Stroke User Manual

OUTBOARD INSTALLATION
104
INSTALLING OUTBOARD
Drilling Outboard Mounting Holes
1. Mark four mounting holes on the transom using the transom
drill fixture.
or69-1
a
a
b
c
a - Drill guide holes
b - Transom drilling fixture
c - Transom center line
Transom Drilling Fixture 91‑98234A2
5489
Aids in engine installation by
acting as a template for engine
mounting holes.

Mercury 60 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	60 hp
Displacement	995 cc
Fuel System	Electronic Fuel Injection (EFI)
Alternator Output	18 amp / 226 watt
Starting	Electric
Cylinders	4 (inline)
Shaft Length	20" or 25"
Full Throttle RPM Range	5000-6000
Warranty	3-Year Limited Warranty
