OUTBOARD INSTALLATION
126
If adjustment is necessary, loosen trim tab bolt and make small
adjustments at a time. If the boat turns more easily to the left, move
the trailing edge of trim tab to the left. If the boat turns more easily
to the right move the trailing edge of trim tab to the right. Retighten
bolt and retest.
Trim‑In Stop Adjustment ‑ Power Trim Models
If an adjustment is required to the trim‑in stop, reposition the tilt
stop pins in the desired holes. Tighten the tilt stop pins to the
specified torque.
a
28538
a - Tilt stop pins
Description Nm lb. in. lb. ft.
tilt stop pins 24.4 18

Mercury 60 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	60 hp
Displacement	995 cc
Fuel System	Electronic Fuel Injection (EFI)
Alternator Output	18 amp / 226 watt
Starting	Electric
Cylinders	4 (inline)
Shaft Length	20" or 25"
Full Throttle RPM Range	5000-6000
Warranty	3-Year Limited Warranty
