Mercury 60 4-Stroke User Manual

MAINTENANCE
91
6. Remove lubricant tube and reinstall cleaned fill/drain plug and
sealing washer.
27001
b
a
c
d
e
a - Front vent plug
b - Front vent hole
c - Rear vent hole
d - Rear vent plug
e - Fill/drain plug and
sealing washer
Submerged Outboard
A submerged outboard will require service within a few hours by
an authorized dealer once the outboard is recovered from the
water. This immediate attention by a servicing dealer is necessary
once the engine is exposed to the atmosphere to minimize internal
corrosion damage to the engine.

Mercury 60 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	60 hp
Displacement	995 cc
Fuel System	Electronic Fuel Injection (EFI)
Alternator Output	18 amp / 226 watt
Starting	Electric
Cylinders	4 (inline)
Shaft Length	20" or 25"
Full Throttle RPM Range	5000-6000
Warranty	3-Year Limited Warranty
