GENERAL INFORMATION
32
Component Identification
a
b
c
e
f
g
h
i
j
k
l
m
n
o
p
q
28524
d
a - Auxiliary tilt switch
b - Tilt support knob
c - Transom brackets
d - Oil drain plug
e - Primary cooling water
intake
f - Gearcase
g - Trim tab
h - Anti‑ventilation plate
i - Driveshaft housing
j - Water pump indicator
hole
k - Bottom cowl
l - Top cowl
m -Shift handle
n - Engine stop switch
o - Throttle friction
adjustment knob
p - Lanyard stop switch
q - Steering friction
adjustment lever (tiller
handle models)
