Mercury 60 4-Stroke User Manual

OUTBOARD INSTALLATION
111
Description Nm lb. in. lb. ft.
Nylon insert locknut "b" 27 20
Nylon insert locknut "e"
Tighten until it seats, then back off 1/4
turn
Assemble steering link rod to steering cable with two flat washers
and nylon insert locknut. Tighten locknut until it seats, then back
nut off 1/4 turn.
Assemble steering link rod to engine with special washer head bolt,
locknut and spacer. First torque bolt, then torque locknut to
specifications.
Fuel Hose Connection ‑ Remote Control Models
REMOTE FUEL HOSE SIZE
Minimum fuel hose inside diameter (ID) is 8 mm (5/16 in.). Use a
separate fuel hose/fuel tank pickup for each engine.
FUEL HOSE CONNECTION
Fasten the remote fuel hose to the fitting with a metal hose clamp
or the plastic type hose clamp that is provided with the outboard.
a
b
28511
a - Hose clamp
b - Remote fuel hose

Mercury 60 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	60 hp
Displacement	995 cc
Fuel System	Electronic Fuel Injection (EFI)
Alternator Output	18 amp / 226 watt
Starting	Electric
Cylinders	4 (inline)
Shaft Length	20" or 25"
Full Throttle RPM Range	5000-6000
Warranty	3-Year Limited Warranty
