OUTBOARD INSTALLATION
124
IMPORTANT: To prevent the propeller hub from corroding and
seizing to the propeller shaft (especially in salt water), always
apply a coat of the recommended lubricant to the entire propeller
shaft at the recommended maintenance intervals, and also each
time the propeller is removed.
2. Flo‑Torq I Drive Hub Propellers ‑ Install forward thrust hub,
propeller, propeller nut retainer and propeller nut onto the
shaft.
a - Propeller nut
b - Propeller nut retainer
c - Propeller
d - Forward thrust hub
3. Flo‑Torq II Drive Hub Propellers ‑ Install forward thrust hub,
propeller, replaceable drive sleeve, rear thrust hub, propeller
nut retainer and propeller nut onto the shaft.
a - Propeller nut
b - Propeller nut retainer
c - Rear thrust hub
d - Replaceable drive
sleeve
e - Propeller
f - Forward thrust hub
4. Place propeller nut retainer over pins. Place a block of wood
between gearcase and propeller and tighten propeller nut to
specifications.
