Mercury 60 4-Stroke User Manual

MAINTENANCE
88
3. Remove vent plug and fill/drain plug and drain lubricant.
a
b
26973
a - Vent plug b - Fill/drain plug
GEARCASE LUBRICANT CAPACITY
Gearcase lubricant capacity is approximately
340 ml (11.5 fl. oz.).
CHECKING GEARCASE LUBRICANT LEVEL AND
REFILLING GEARCASE
1. Place outboard in a vertical operating position.
2. Remove vent plug.
3. Place lubricant tube into the fill hole and add lubricant until it
appears at the vent hole.
IMPORTANT: Replace sealing washers if damaged.
4. Stop adding lubricant. Install the vent plug and sealing washer
before removing the lubricant tube.

Mercury 60 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	60 hp
Displacement	995 cc
Fuel System	Electronic Fuel Injection (EFI)
Alternator Output	18 amp / 226 watt
Starting	Electric
Cylinders	4 (inline)
Shaft Length	20" or 25"
Full Throttle RPM Range	5000-6000
Warranty	3-Year Limited Warranty
