GASOLINE STERNDRIVE INSTALLATION MANUAL
90-860172011 Page 109 of 137
WARNING
If engine is to be tested with boat out of water, the propeller must be removed to
avoid injury.
IMPORTANT: If using a test tank, ensure water level is above water intake holes.
70082
b
a
a-Minimum Water Level
b-Water Intake Holes
CAUTION
If using flush test device, install over water intake holes and connect a water hose
as shown. Do not use full water tap pressure. Also, do not run engine above 1500
rpm, as suction created could cause water hose to collapse causing water supply
to be cut off.
77899
Dual Water Pickup Low Water Pickup Side Pickup
