Mercury Optimax 135 Service Manual

LEFT HAND NON-RATCHETING
Page 6B-2 90-855347R1 JANUARY 1999
Special Tools
1. Shift Shaft Bushing Tool 91-31107T
2. Gear Housing Cover Nut Tool 91-61069
3. Bearing Carrier Removal Tool 91-46086A1 and Puller Bolt 91-85716
4. Slide Hammer Puller 91-34569A1
5. Bearing Removal and Installation Kit 91-31229A5. This kit contains the following
tools: Pilot 91-36571; Puller Rod 91-31229; Nut 11-24156; Puller Plate 91-29310;
Mandrel 91-38628; and Driver Rod 91-37323.
6. Pilot 91-36571
7. Puller Rod 91-31229 and Nut 91-24156

Mercury Optimax 135 Specifications

General

Engine Type	V6
Horsepower	135 HP
Fuel Induction System	2-stage direct fuel injection
Full Throttle RPM Range	5000-5750 RPM
Alternator Output	60 amp / 756 watt
Starting System	Electric
Steering	Remote
Dry Weight	431 lbs
Shaft Length	20", 25"
