Mercury SMARTCRAFT User Manual

SYSTEM TACH & SPEED
Part 3
System Tach and Speedometer
Basic Operation and Features 3-1. . . . . . . . . . . . . . . .
Auto Detection Engine Function 3-3. . . . . . . . . . . . . .
Master Reset 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer Display Screens 3-4. . . . . . . . . . . . . . .
Tachometer Display Screens 3-6. . . . . . . . . . . . . . . . .
Troll Control 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning System 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Display Screens 3-11. . . . . . . . . . . . . . . . . . .
Cal 1 Tachometer Calibration 3-15. . . . . . . . . . . . . . . .
Cal 2 Tachometer Calibration 3-18. . . . . . . . . . . . . . . .
Cal 1 Speedometer Calibration 3-22. . . . . . . . . . . . . .
Cal 2 Speedometer Calibration 3-24. . . . . . . . . . . . . .
NOTE:This manual shows all the Monitor display
screens that are available. Depending on your type
of engine, not all these screens will apply.
System Tach and Speedometer are compatible
with:
2002 model year Mercury Outboard models that are
designed for use with SmartCraft.
MerCruiser model 8.1/496

Mercury SMARTCRAFT Specifications

General

Display Type	LCD
Connectivity	NMEA 2000
Manufacturer	Mercury Marine
Category	Boating Equipment
Features	fuel management
Data Provided	fuel consumption
Type	Engine Monitor
