Mercury SMARTCRAFT - Part 4 Smart Tach and Speedometer

VDO
SMART TACH & SPEED
Part 4
Smart Tach and Speedometer
Basic Operation and Features 4-1. . . . . . . . . . . . . . . .
Speedometer Display Screens 4-2. . . . . . . . . . . . . . .
Tachometer Display Screens 4-4. . . . . . . . . . . . . . . . .
Troll Control 4-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning System 4-8. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Display Screens 4-9. . . . . . . . . . . . . . . . . . . .
Tachometer Calibration 4-12. . . . . . . . . . . . . . . . . . . . .
Speedometer Calibration 4-17. . . . . . . . . . . . . . . . . . .
NOTE:This manual shows all the Monitor display
screens that are available. Depending on your type
of engine, not all these screens will apply.
Smart Tach and Speedometer are compatible
with:
2001 model year and newer Mercury Outboard mod-
els that are designed for use with SmartCraft.
