MONITOR 2.00
2-5
MONITOR – VERSION 2.00
Standard Information Display Screens
NOTE:This manual shows all the Monitor display screens that are
available. Depending on your type of engine, not all these screens
will apply.
Start Up
At start up, a momentary (1 sec-
ond) screen displays the current
monitor software version, fol-
lowed by a 4 second display
showing hours of engine use.
Fuel Used
Displays approximate fuel used
since the last reset. Reset will
return display back to 0.
You can Reset anytime by
pressing and
buttons together momentarily.
Engine RPM
Tachometer – Displays engine
speed in Revolutions Per Min-
ute (RPM).
Fuel Flow
Displays current estimated indi-
vidual engine fuel consumption
in Gallons per hour (Gal/hr) or
Liters per hour (Ltr/hr).
To Next Page
