SYSTEM TACH & SPEED
3-7
SYSTEM TACH & SPEEDOMETER
8
7
9
Tachometer
0
1
2
3
4
5
6
7
HRS
VOLT
22.3
13.6
3200
FUEL
USED
2.4
22.0
6
OIL
PSI
DEPTH
FEET
Tachometer Display Screens
6. Oil Pressure – Displays engine oil pressure in units of Psi or Bar.
7. Battery Voltage – Displays voltage level (condition) of battery.
Also records the running time of engine.
8. Fuel Flow – Displays engine fuel use in gallons per hour or liters
per hours.
9. Digital Tachometer – Displays engine speed in Revolutions
Per Minute (RPM).
10. Water Depth – Displays the depth of water under the transducer
if connected. The water depth screen can be turned on or off in
CAL 1 Calibration. You can set an alarm to trigger whenever the
boat moves into water shallower than the alarm level. Refer to
CAL 2 Calibration for water depth alarm and offset settings.
NOTE:You must have a depth transducer (purchased separately)
connected to the system in order for this screen to operate.
To Next Page
