SYSTEM TACH & SPEED
3-16
SYSTEM TACH & SPEEDOMETER
CAL 1 Tachometer Calibration
TRIM CALIBRATION
[EDIT][SKIP]
Choosing edit allows you to calibrate
the gauge to the standard 0–10 unit trim
and 11–25 trailer position scale.
TRIM FULL DOWN THEN
PRESS PLUS BUTTON
[SAVE]
[SKIP]
[DFLT]
TRIM FULL UP THEN
PRESS PLUS BUTTON
[SAVE]
[SKIP]
[DFLT]
TRIM TO TRAILER POINT
THEN PRESS PLUS BUTTON
[SAVE]
[SKIP][DFLT]
DISPLAY UNITS
[DOWN]
[UP]
[SAVE]
Lets you change units of measure
between English (standard) or Metric.
SPEED UNITS
[DOWN]
[UP]
[SAVE]
Lets you select speed units. You can
choose from MPH (Miles Per Hour), KN
(Nautical Miles Per Hour) or KMH
(Kilometers Per Hour).
[NO]
[YES]
[SAVE]
DEPTH SCREEN?
Do you want to turn on the depth screen?
(Remember: You must have a Smart
Craft depth transducer connected to the
system for this screen to operate)
ENGINE TEMP SCREEN?
[NO]
[YES]
[SAVE]
Do you want to turn on the engine temp
screen?
(continued on next page)
