SYSTEM TACH & SPEED
3-19
SYSTEM TACH & SPEEDOMETER
CAL 2 Tachometer Calibration
SPEED OPTION
[EDIT]
[SKIP]
This section lets you configure the
following speed sensors.
PITOT SENSOR?
[NO]
[YES]
[SAVE]
Select pitot transducer type. You can
choose 100 or 200 PSI. (100 PSI is the
most common)
PITOT SENSOR MULTIPLIER
[DOWN]
[UP]
[SAVE]
Adjust the pitot pressure sensor for
correcting display readings that are to
high/low.
PADDLE SENSOR PULSE FAC-
TOR
[DOWN]
[UP]
[SAVE]
Adjust paddle wheel frequency for display
readings that are to high/low.
PADDLE TO PITOT TRANSITION
[DOWN]
[UP]
[SAVE]
Set the speed at which the gauge stops
looking at the paddle wheel and starts
using pitot to measure boat speed.
(continued on next page)
There are three methods for calibrating fuel tank level
monitoring feature:
First: Do nothing. Linear readout based on raw sensor values. This
mode does not factor in irregular tank shapes.
Second: By following the tank calibration procedure described on
next page, but without actually adding fuel. System Tach will supply
an estimated range value based on linear interpolation of the sensor
range values. This mode does not factor in irregular tank shapes.
Third: By following the tank calibration procedure described on next
page completely, which means adding fuel at each calibration point.
System Tach will display an estimated range value that factors in the
tank shape.
To Next Page
