Mercusys Halo S3 User Manual

15
300Mbps Whole Home Mesh Wi-Fi System
Halo S3
Click the Save button to save your settings.
4.3.3 IPTV Settings
In this page you can congure IPTV related features.
Note:
IPTV and its related features are only supported on the main router.
• IGMP Snooping - IGMP snooping is designed to prevent hosts on a local network
from receiving trac for a multicast group they have not explicitly joined. IGMP
snooping is especially useful for bandwidth-intensive IP multicast applications
such as IPTV.
• IGMP Proxy - Select to enable IGMP Proxy.
• IGMP Version - Select the IGMP (Internet Group Management Protocol) Proxy
Version, either V2 or V3, according to your ISP.
• IPTV - Select to enable the IPTV feature.
• Mode - Select the appropriate mode according to your ISP.
4.3.4 MAC Clone
You can congure MAC Clone features of your main router on this page.
• WAN MAC Address - This eld displays the current MAC address of the WAN port.
If your ISP requires that you register the MAC address, please enter the correct
MAC address into this eld. The format for the MAC Address is XX:XX:XX:XX:XX:XX
(X is any hexadecimal digit).
• Your PC's MAC Address - This eld displays the MAC address of the PC that is
managing the router. If the MAC address of your adapter is registered, you can click
the Clone MAC Address button , then it will be lled into the WAN MAC Address
eld.
Click Restore Factory MAC to restore the MAC address of WAN port to the factory
default value.
Click the Save button to save your settings.

Mercusys Halo S3 Specifications

General

Mesh Technology	Yes
MU-MIMO	Yes
Beamforming	Yes
Parental Controls	Yes
Guest Network	Yes
Frequency Band	2.4 GHz, 5 GHz
Wireless Security	WPA3
