7 Assembly
17. Install the rear output front bearing cup into the housing.
Figure 7.41.
Front Bearing
Cup
4018273a
Figure 7.41
18. Install all declutch housing gasket shims that were removed
during disassembly. Install the declutch housing onto the main
housing using Loctite 272 threadlocker. Torque the bolts to
specifi cation in a crisscross pattern. Figure 7.42.
4018274a
Figure 7.42
19. Install the rear output shaft into the housing from the rear.
Figure 7.43.
Rear Output
Shaft
401827
Figure 7.43
20. Install the intermediate shaft assembly into the housing. Figure
7.44.
Intermediate
Shaft
4018276a
Figure 7.44
To Next Page
