Merrychef eikon e1s - Cooking profiles; Creating a cooking profile

21
eikon e1s
User Manual
Section 2: Operations and Installation Guide
2E. Cooking profiles
Creating a cooking profile
1. Enter development mode
Select the ‘chef’s hat’ symbol from
the main menu screen to enter
development mode.
2. Set the microwave power
The temperature value displays
the set preheating temperature.
To change the temperature, select
the ‘temperature’ symbol, and
enter a value within the limits
displayed.
Select the green tick to continue.
3. Set the cooking time
Select the ‘clock’ symbol and enter
the cooking time for each stage up
to a maximum of 10 minutes.
Example: Enter 110 = 1 minute and
10 seconds.
Select the green tick to save the
inserted value.
4. Set the microwave power
Select the ‘microwave’ symbol and
set the microwave power (0 and 5-
100%).
Select the green tick to save the
inserted value.
5. Set the fan speed
Select the ‘fan’ symbol and set the
fan speed within the limits shown on
the screen.
Select the green tick to save the
inserted value.
6. Enter instruction for a stage
(optional)
Select the ‘information’ symbol to
enter instruction for a stage.
Example: ‘Stage 1 - place a food
product into the cavity‘.
Select the green tick to save the
inserted instruction.
Select the right arrow with a ‘plus’
symbol at the bottom to add a new
stage by repeating the steps above.
Note:
• Cooking profiles can have up to a
maximum of six stages.
• The ‘magnifier’ symbol at the top
indicates which stage is displayed.
• Select the left/right arrow at the
bottom to shift between the
stages.
