60
Service & Parts Manual original Instructions
Part Number 32Z3809 GB
Issue 1
ELECTRICAL
CIRCUITS
N L
13
2
12
8
5
8
12
23
24
222
20
X.10
x4a
2
13
44
46
48
55
56
FA F
MW
57
1
47
x102b x102a
x4b1
21
45
45
N
N L
47
45
48
46
Hybrid
Relay
Safety Relay
Microwave. Powered
by Safety Supply relay
Filter 2
LHS SW3
normally
open
Current Sense
To SRB E101 Sense
Fuse 4
RHS SW1
normally
closed
Door Switches shown in
door open position
RHS SW2
normally
open
Fuse 2
20 Amp
10 Amp
HV Transformer
Diode Board
Filter 2
Filter 4
Filter 4
Filter 4. Connector view
Filter 2. Connector view
MICROWAVE CIRCUIT e3XE & e3XX25.8
L1 TWIN PHASE MODEL
L SINGLE PHASE MODEL
