SPARE PARTS22
Parts list & recommended minimum stock holding & Service Kits
Exploded
BOM No.
Part
Number
Description
Qty
Per
Oven
Unit
1-10
Ovens
11-50
Ovens
51-100
Ovens
1st
Aid/
To Go
Box
Service
Centre
Kit
1 105005 M3 CAGE NUT 9 EA 9 27 54
2 30Z0217 FUSE 1in 10A HRC 1 EA 2 6 12 2 4
3 30Z0231 FUSEHOLDER 1in (13A) 2 EA 1 2 4 1 2
4 30Z0240 MICROSWITCH 2 EA 2 6 12 2 4
5 30Z0503 SWITCH ON/OFF ROCKER DPST 1 EA 1 3 6 1 1
6 30Z1177 20 AMP LITTLEFUSE FLM020 2 EA 2 6 12 2 4
7 30Z1178 30A FUSE HOLDER 2 EA 1 3 6 1 2
8 30Z1207 FUSE 1in 3A HBC 1 EA 2 6 12 2 4
9 30Z1298 CAPACITOR - MOTOR START 2 EA 2 6 12 1 2
10 30Z1340 FILTER 16A SCREW MOUNT 4 EA 2 6 12 1 4
11 30Z1415 MAGNETRON 2M303H 1 EA 1 3 6 1 2
12 30Z1418 ECOFIT COOLING FAN 1 EA 1 3 6 1
13 30Z1425 LV TRANSFORMER 1 EA 1 3 6 1 2
14 30Z1427 MAGNETRON OVERHEAT STAT 1 EA 1 3 6 1 1
15 30Z1430 MICROSWITCH (LARGE) 1 EA 1 3 6 1 1
16 30Z5000 SMART RELAY BOARD SRB 1 EA 1 3 6 1
17 30Z5002 TOUCH SCREEN PCB 1 EA 1 3 6 1
18 31Z0115 INSULATOR PAD 2 EA 2 6 12
19 31Z0166 3-WAY TERMINAL BLOCK 2 EA 2 6 12 1
20 31Z0186 SILASTIC BLACK (DOOR SEAL) TUBE 1 3 6 1 1
21 31Z0477 4 WAY MAINS TERMINAL BLOCK 1 EA 1 3 6 1
22 31Z0599 BTS UI SRB CABLE (WHITE) 1 EA 1 3 6 1 1
23 31Z0600 USB ADAPTOR MODULE 1 EA 1 3 6 1
24 31Z1259 SHEET COVER CAP 12MM DIA 6 EA 6 18 36
25 31Z1307 ETHERNET HOLE PLUG 1 EA 1 3 6
26 31Z4037 M5 KNURLED COIN SLOT THUMB NUT 3 EA 2 6 12 1
27 31Z4041 FAN BLADE 1 EA 1 3 6
28 31Z4042 MOTOR COOLING FAN BLADE 1 EA 1 3 6
29 31Z7086 REED SWITCH RETAIN CLIP 1 EA 1 3 6 1
30 32Z1066 DOOR HANDLE 1 EA 1 3 6
31 32Z7061 PERSONALITY MODULE SRB e3 1 EA 1 3 6 1
32 32Z7064 PERSONALITY MODULE BTS e3 1 EA 1 3 6 1
33 40H0046 CAPACITOR CLIP - SINGLE 2 EA 2 6 12
34 40H0190 TEFLON SHEET 3 EA 3 9 18
35 40H0221 EC403 CAT COVER (REMOVABLE) 1 EA 1 3 6
36 40H0249 CAST TURNTABLE DISK 1 EA 1 3 6 1
37 40H0262F CAST TURNTABLE COATED 2 EA 2 6 12 1
38 DR0005 4 COIL DUAL HEAT ELEMENT 3.2kW 1
EA 1 3 6 1
39 DR0006 REED SWITCH 1 EA 1 3 6 1 1
40 DR0007 MERRYCHEF BADGE 1 EA 1 3 6
41 DR0008 MERRYCHEF BADGE SLIDER 1 EA 1 3 6
42 DR0009 MERRYCHEF BADGE GUIDE 1 EA 1 3 6
43 DR0010 MERRYCHEF BADGE SEAL 1 EA 1 3 6
44 DR0011 TOUCHSCREEN OVERLAY 1 EA 2 6 12 1
45 DR0020 CAVITY TEMP SENSOR (OVEN) 1 EA 1 3 6 1 1
46 DR0021 HARMONISED SPEAKER 1 EA 1 3 6 1
47 DR0043 OVERHEAT STAT LARGE 1 EA 1 3 6 1 1
48 DV0202 CERAMIC PLATE RETAINER 2 EA 2 6 12 2
49 DV0666 STIRRER COVER - CERAMIC 1 EA 1 3 6 1 2
50 DV0692 SEAL - CERAMIC COVER 1 EA 1 3 6 1 2
51 DX0005 CONTROL BOX 1 EA 0 1 2
52 DX0018 DOOR CHOKE 1 EA 0 1 2
53 DX0019 DOOR SKIN 1 EA 0 1 2
54 DX0020 TOP PANEL 1 EA 0 1 2
To Next Page
