Exploded
BOM No.
Part
Number
Description
Qty
Per
Oven
Unit
1-10
Ovens
11-50
Ovens
51-100
Ovens
1st
Aid/
To Go
Box
Service
Centre
Kit
55 DX0021 RHS CASEWORK 1 EA 0 1 2
56 DX0022 LHS CASEWORK 1 EA 0 1 2
57 DX0031 CAVITY SHELF RUNNER 4 EA 2 6 12
58 DX0035 STEAM PIPE 1 EA 1 3 6
59 DX0058 HOT BOX 2 MOTOR SEAL 1 EA 0 1 2 1
60 DX0059 CAVITY 2 HOT BOX SEAL 1 EA 0 1 2 1
61 DX0083 FRONT TRIM SEAL 1 EA 0 1 2
62 MC3175 OVEN TRAY 2 EA 2 6 12
63 MC3215 TRAY HANDLE 1 EA 0 1 2
64 30Z5008 DIODE PCB ASSY 1 EA 1 3 6 1 1
65 PSA288 STIRRER MOTOR ASSY (PINNED) 1 EA 1 3 6 1
66 PSA291 STIRRER ASSY (PINNED) 1 EA 1 3 6 1
67 PSX202 DOOR ASSY 1 EA 0 1 2
68 PSX209 HOT AIR MOTOR SUB-ASSY 1 EA 1 3 6 1
69 SA374 CAST WAVEGUIDE ASSY 1 EA 0 1 2
70 / 72 PSR101 EIKON DOOR HINGE KIT 1 EA 1 3 6 1
71 / 73 PSR102 EIKON M/SWITCH BRACKET KIT 1 EA 1 3 6 1
74 PSX203 TURNTABLE DRIVE ASSY 1 EA 1 3 6 1 1
75 SX305 REAR CASEWORK ASSY 1 EA 0 1 2
76 SX306 MAG EXHAUST DUCT ASSY 1 EA 0 1 2
77 SX307 DOOR SEAL ASSY 1 EA 1 3 6 1 1
78 SX309 AIR FILTER ASSY 1 EA 1 3 6 1 1
79 SX314 WAVEGUIDE AIR DUCT 1 EA 0 1 2
80 SX315 CERAMIC CAT CONVERTER 1 EA 0 1 2
eikon e3 EE - 230Volts 50HZ - UK/EU - Unique Parts
81 30Z1330 0.88uF 2500V CAPACITOR 1 EA 1 3 6 1 1
82 30Z1413 230V 50Hz TRANSFORMER 1 EA 1 3 6 1
83 30Z1440 RELAY 240V OMRON 1 EA 1 3 6 1 1
84 31Z1308 CABLE GLAND PG16 1 EA 1 3 6
85 31Z1309 GLAND NUT PG16 1 EA 1 3 6
DX0101 MAINS SUPPLY LEAD A (UK) 1 EA 1 3 6
DX0103 MAINS SUPPLY LEAD C (EU) 1 EA 1 3 6
eikon e3 EE - 220Volts 60HZ - EU - Unique Parts
81 30Z1332 1.05uF CAPACITOR 2500V 1 EA 1 3 6 1 1
82 30Z1230 60HZ TRANS MULTI TAP 1 EA 1 3 6 1
83 30Z1440 RELAY 240V OMRON 1 EA 1 3 6 1 1
84 31Z1308 CABLE GLAND PG16 1 EA 1 3 6
85 31Z1309 GLAND NUT PG16 1 EA 1 3 6
DX0106 MAINS SUPPLY LEAD CE 1P (UK/EU) 1 EA 1 3
6
eikon e3 XE - 230Volts 50HZ - UK/EU - Unique Parts
81 30Z1330 0.88uF 2500V CAPACITOR 1 EA 1 3 6 1 1
82 30Z1413 230V 50Hz TRANSFORMER 1 EA 1 3 6 1
84 31Z1255 CABLE GLAND BLACK PG21 1 EA 1 3 6
85 31Z1256 NUT FOR CABLE GLAND PG21 1 EA 1 3 6
DX0102 MAINS SUPPLY LEAD BC 2P (UK) 1 EA 1 3 6
DX0106 MAINS SUPPLY LEAD CE 1P (UK/EU) 1 EA 1 3 6
DX0109 MAINS SUPPLY LEAD BD 2P (EU) 1 EA 1 3 6
