Merrychef eikon e3 Service & Parts Manual

Service & Parts Manual original Instructions
Part Number 32Z3809 GB
Issue 1
45
SPARES &
REPLACEMENT
Exploded
BOM No.
Part
Number
Description
Qty
Per
Oven
Unit
1-10
Ovens
11-50
Ovens
51-100
Ovens
1st
Aid/
To Go
Box
Service
Centre
Kit
eikon e3 XX - 230Volts 50HZ - UK/EU - Unique Parts
81 30Z1431 1.2uF 2500V CAPACITOR 1 EA 1 3 6 1 1
82 30Z1413 230V 50Hz TRANSFORMER 1 EA 1 3 6 1
84 31Z1255 CABLE GLAND BLACK PG21 1 EA 1 3 6
85 31Z1256 NUT FOR CABLE GLAND PG21 1 EA 1 3 6
DX0102 MAINS SUPPLY LEAD BC 2P (UK) 1 EA 1 3 6
DX0106 MAINS SUPPLY LEAD CE 1P (UK/EU) 1 EA 1 3 6
DX0109 MAINS SUPPLY LEAD BD 2P (EU) 1 EA 1 3 6
eikon e3 XX - 230Volts 50HZ - AZ - Unique Parts
81 30Z1431 1.2uF 2500V CAPACITOR 1 EA 1 3 6 1 1
82 30Z1413 230V 50Hz TRANSFORMER 1 EA 1 3 6 1
84 31Z1255 CABLE GLAND BLACK PG21 1 EA 1 3 6
85 31Z1256 NUT FOR CABLE GLAND PG21 1 EA 1 3 6
DX0102 MAINS SUPPLY LEAD BC 2P (UK) 1 EA 1 3 6
eikon e3 XX - 230Volts 50HZ - CN - Unique Parts
81 30Z1431 1.2uF 2500V CAPACITOR 1 EA 1 3 6 1 1
82 30Z1413 230V 50Hz TRANSFORMER 1 EA 1 3 6 1
84 31Z1255 CABLE GLAND BLACK PG21 1 EA 1 3 6
85 31Z1256 NUT FOR CABLE GLAND PG21 1 EA 1 3 6
DX0110 MAINS SUPPLY LEAD JE 1P (CN) 1 EA 1 3 6
eikon e3 XX - 220Volts 60HZ - SA - Unique Parts
81 30Z1332 1.05uF CAPACITOR 2500V 1 EA 1 3 6 1 1
82 30Z1230 60HZ TRANS MULTI TAP 1 EA 1 3 6 1
84 31Z1255 CABLE GLAND BLACK PG21 1 EA 1 3 6
85 31Z1256 NUT FOR CABLE GLAND PG21 1 EA 1 3 6
DX0106 MAINS SUPPLY LEAD CE 1P (UK/EU) 1 EA 1 3 6
All above oven variations can be tted with or without Catalytic Converters (see Main List for part no.)
