8
Scanner 8150 / 8250 / 8310 / 8312
Specification Model
8150/8250
Model
8310/8312
Operational
Light Source 660 nm Visible
Red LED
630 nm Visible
Red LED
Optical System 2048 pixel CCD
(Charge-coupled device)
Depth of Scan
Field
0-250 mm
(CODE 39,
PCS=90%,
20mils)
Up to 600mm
(CODE 39,
PSC=90%,
20mils)
Scanning Width 120 mm 160mm
Scan Speed 200 scans/sec 450 scans/sec
Resolution 0.1mm(4mils)
Code39,PCS=90%
0.1mm(4mils)
Code39,PCS=90%
Print Contrast 30% or more 25% or more
Scanning Angle Front: 60° Rear: 60° Yaw: 75°
Decode Capability Autodiscriminates all standard
barcodes; Other symbologies can be
ordered optionally (2D symbologies
for 8250 and 8312 only)
Beeper Operation 7 tones or no beep
Indicator Green led Green & Red led
Mechanical
Length 182 mm 164 mm
Width-handle 26 mm 30 mm
Width-head 74 mm 78 mm
Depth-handle 51 mm 56 mm
