Meteor 8310 - Code Option Settings

26
Pin Assignments
AS Series RJ-45 Connector (AS-8110, 8150, 8250)
Pin RS-232 Keyboard
1 VCC (+5V) VCC (+5V)
2 TXD NA
3 NA CLK / PC
4 NA DATA / PC
5 CTS DATA / KB
6 RXD NA
7 RTS CLK / KB
8 GND GND
8-pin (8110, 8150, 8250) 10-pin (8310,
8312)
AS Series RJ-45 Connector (AS-8310, 8312)
Pin RS-232 Keyboard
1 I/F I/F
2 VCC (+5V) VCC (+5V)
3 TXD NA
4 NA CLK / PC
5 NA DATA / PC
6 CTS DATA / KB
7 RXD NA
8 RTS CLK / KB
9 GND GND
1
2
4
3
5
6
7
8
1
2
4
3
5
6
7
8
9
10
