A 1785 PV Remote WL Instrument description
10
2.3 Back side
Figure 2-3: Back side
Legend:
1
Side belt
2
Battery compartment cover
3
Fixing screw for battery compartment cover
4
Back panel information label
5
Holder for inclined position of the instrument
Figure 2-4: Battery compartment
Legend:
1
Battery cells
Size AA, alkaline or rechargeable NiMH / NiCd
2
Serial number label
