METREL PV Remote WL User Manual

A 1785 PV Remote WL Instrument operation
13
3 Instrument operation
3.1 Function selection
For selecting main functions the FUNCTION SELECTOR shall be used.
Keys
FUNCTION SELECTOR
Select function:
▪ <SOLAR> Measurements
▪ <SETTINGS> Instrument settings
3.2 Settings
In the SETTINGS menu:
- language can be selected,
- communication with PV instrument
can be configured/established,
- memory can be cleared,
- irradiance sensor can be configured
and
- ambient temperature or second cell
temperature can be configured.
Figure 3-1: Options in Settings menu
Keys
UP / DOWN
Selects option.
TEST
Enters menu for selecting parameter.
3.2.1 Language
In this menu the language can be set.
Figure 3-2: Language selection
Keys
UP / DOWN
Selects language.
TEST
Confirms selected language.
