MI 3201 TeraOhm 5 kV Plus Measurements
23
Measurement procedure:
- Connect the test leads to the instrument and to the test object.
- Select INSULATION RESISTANCE function in MAIN MENU.
- Press the START/STOP key and release it, continuous measurement will begin.
- Wait until the test result has stabilized then press the START/STOP key again to
stop the measurement or, if enabled, wait for the set timer runs out.
- Wait for the object under test to discharge.
- The result can optionally be saved pressing the MEM key twice, see chapter 6.1.
Store, Recall and Clear Operation.
Legend of displayed symbols:
fil0 (Fil1, Fil2, Fil3)
Filter type enabled, see the chapter 5.3.
Configuration
5000V
Set test voltage
U=5323V
Actual test voltage – measured value
I=266nA
Actual test current – measured value
19.9G
Insulation Resistance – result
C=0.0nF
Capacitance of measured object
tm:04min 26s
Timer information – test duration
Bar
Analogue representation of result
Rmax=20.1G
Maximum value of result (only if timer is
enabled)
Rmin=19.9G
Minimum value of result (only if timer is
enabled)
Notes:
- If the timer is disabled then OFF is displayed instead of the timer value.
- During a measurement, the timer information displays the time needed to the
complete the measurement (tr) while after the completion the test duration (tm) is
displayed.
- A high-voltage warning symbol appears on the display during the measurement to
warn the operator of a potentially dangerous test voltage.
- Value of capacitance is measured during the final discharge of the test object.
