MI 3201 TeraOhm 5 kV Plus Measurements
37
Legend of displayed symbols:
WITHSTANDING VOLTAGE DC
Name of selected function
1000V
Start test voltage
5000V
Stop test voltage
5275V
Actual test voltage – measured value
I=0.001mA
Actual test current – measured value
tm:01min 00s
Timer information
Measuring procedure:
- Connect the test leads to the instrument and to the measured object.
- Press the START/STOP key to start the measurement.
- Wait until the set timers runs out or until breakdown occurs, (the result will be
displayed).
- Wait for the object under test is discharge.
- The results can be saved by pressing the MEM key twice, see the chapter 6.1.
Storing, Recalling and Clearing Results.
Note:
- Breakdown is detected when the measured current reaches or exceeds the set
current level Itrig.
Notes:
- The timer shows the time needed to complete each step during the measurement
and it shows the total measurement period after the completion of the measurement.
- A high-voltage warning symbol appears on the display during the measurement to
warn the operator of a potentially dangerous test voltage.
Legend of displayed symbols:
WITHSTANDING VOLTAGE DC
Name of selected function
SETTING PARAMETERS:
Ustart
1000V
Start test voltage, step = 25 V
Ustop
5000V
Stop test voltage, step = 25 V
Tstep 00min 00s
Duration of test voltage per one step
Tend 01min 00s
Duration of constant test voltage after reaching stop
value
Itrigg 1.000mA
Set trigger leakage current, step = 10 A
