3 Installation
Combustion-IC-System
￭￭￭￭￭￭￭￭
15
Connect
capillary/
tubing at
port …
… to
4 930 Compact IC Flex (see chapter 3.6.5, page 21)
5 Metrosep I Trap1 - 100/4.0 (6.1014.200)
You can find detailed instructions in the manual for the 920 Absorber
Module.
3.6 Connecting the 920 Absorber Module to the remain-
ing components
Combustion Module (AJ)
Three capillaries are routed out at the right side of the Combustion-IC-Sys-
tem.
￭ The capillary connected to port 4 of the Dosino for ultrapure water is
marked with a blue colored sleeve.
￭ The capillary connected to the outlet of the Metrosep A Trap 1 –
100/4.0 is marked with a yellow colored sleeve.
￭ The thicker capillary installed at the inlet of the absorber tube is routed
out under the door.
Combustion Oven (TEI)
Three capillaries are routed out at the back and/or left side of the Com-
bustion Oven (TEI).
￭ The capillary connected to port 4 of the Dosino for ultrapure water is
marked with a blue colored sleeve. The capillary is part of
6.07311.310. The other end of the capillary is already connected.
￭ The capillary connected to the outlet of the Metrosep A Trap 1 –
100/4.0 is marked with a yellow colored sleeve. The other end of the
capillary is already connected to the oven outlet.
￭ The thicker capillary installed at the inlet of the absorber tube is routed
out at the rear. The other end of the capillary is already connected to
the oven outlet.
