Metrohm Combustion-IC-System - Connecting the Combustion Oven (TEI) Inlet; Figure 11 Combustion Tube - Inlet

3.6 Connecting the 920 Absorber Module to the remaining components
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
20
￭￭￭￭￭￭￭￭
Combustion-IC-System
3.6.3 Connecting the Combustion Oven (TEI) inlet
Figure 11 Combustion tube – Inlet
1
Argon infeed
Connection for the argon infeed.
2
Oxygen infeed
Connection for the oxygen infeed.
3
Oxygen infeed
Connection for the oxygen infeed.
4
Water infeed inlet
Connector for the ultrapure water supply.
