60/30 (40) HR:80 BPM PP:2.00 mmHg.> F7
80/48 (58) HR:80 BPM PP:2.00 mmHg.> F6
100/65 (77) HR:80 BPM PP:2.00 mmHg.> F5
MORE GO BACK START MAIN MENU
F1 F2 F3 F4
To select the desired preset use the F5, F6 or F7 key. The corre-
sponding line will flash intermittently to indicate the selected pre-
set. Below are the adult and neonate preset pressures.
Adult Preset Pressures
Diastolic//Systolic
(mmHg)
MAP (mmHg) Heart Rate
(BPM)
Pulse Pressure
(mmHg)
60 / 30 40 80 3.00
80 / 48 58 80 3.00
100 / 65 77 80 3.00
120 / 80 95 80 3.00
150 / 95 114 80 3.00
200 / 140 167 80 3.00
255 / 195 215 80 3.00
Neonate Preset Pressures
Diastolic//Systolic
(mmHg)
MAP (mmHg) Heart Rate
(BPM)
Pulse Pressure
(mmHg)
60 / 30 40 120 1.50
80 / 48 58 120 1.50
100 / 65 77 120 1.50
120 / 80 95 120 1.50
150 / 95 114 120 1.50
200 / 140 167 120 1.50
255 / 190 220 120 1.50
In the present pressure screen menu keys press:
• MORE (F1) to advance to the next preset screen.
• GO BACK (F2) to return to the Adult/Neonate Screen.
• START (F3) to advance to the BP Test Screen.
• MAIN MENU (F4) to return to Main Menu Screen 1.
4.22 Independent Test Parameters (F1). From the menu shown be-
low( from BP Test at Main Menu) select more and then (F7) to set
the desired blood pressure, heart rate or pulse amplitude and Ar-
rhythmias.
