6. SPECIFICATIONS & TECHNICAL INFORMATION
Table 1 - Torque & VA Ratings
Torque
Output at
breakaway
Speed
(seconds
per 90˚
rotation)
Duty
Cycle
VA Rating Max Running
Current at Full Load
(True MS)
Max Eective Peak
Inrush Current (= .66 x)
Peak rush
115 VAC 230 VAC 115VAC 230 VAC 115 VAC 230 VAC
150 lb•in;
12 lb•ft; 17 Nm
8 75% 70 vA 115 vA 0.6 amps 0.5 amps 1.25 amps 0.924 amps
300 lb•in;
25 lb•ft; 34 Nm
15 75% 70 vA 115 vA 0.6 amps 0.5 amps 1.25 amps 0.924 amps
600 lb•in
50 lb•ft; 68 Nm
30 75% 70 vA 115 vA 0.6 amps 0.5 amps 1.25 amps 0.924 amps
1000 lb•in
83 lb•ft; 113 Nm
25 75% 92 vA 161 vA 0.8 amps 0.7 amps 1.66 amps 1.29 amps
1500 lb•in
125 lb•ft; 169 Nm
40 75% 92 vA 161 vA 0.8 amps 0.7 amps 1.66 amps 1.29 amps
2000 lb•in
167 lb•ft; 226 Nm
55 75% 92 vA 161 vA 0.8 amps 0.7 amps 1.66 amps 1.29 amps
2500 lb•in
208 lb•ft; 282 Nm
70 75% 92 vA 161 vA 0.8 amps 0.7 amps 1.66 amps 1.29 amps
3000 lb•in
250 lb•ft; 339 Nm
75 55% 92 vA 161 vA 0.8 amps 0.7 amps 1.66 amps 1.29 amps
Table 2 - Specications
Temperature Range -40°F to 150°F (-40°C to 65°C)
Conduit Connections
(2) 3/4” NPT in sizes up to 600 lb•in (3/4” to 1/2” reducing bushings included)
(2) 3/4” NPT in sizes 1000 lb•in and above (3/4” to 1/2” reducing bushings included)
Output
150 to 600 lb•in (12 - 25 lb•ft; 17 - 68 Nm) ISO 5211 F05 and F07 bolt circles, 3/4” female square (14mm female square w/ “I”
Option; 15mm female keyed output w/ “Y” Option).
1000 to 3000 lb•in (83 - 250 lb•ft; 113 - 339 Nm): ISO 5211 F07 and F10 bolt circles, 1” female square (1000 lb•in (83 lb•ft;
113 Nm): 19mm female square w/ “I” Option; 1500 - 3000 lb•in (125 - 250 lb•ft; 169 - 339 Nm) : 22mm female square w/ “I”
Option; 1000 to 3000 lb•in (83 - 250 lb•ft; 113 - 339 Nm): 20mm female keyed output w/ “Y” Option)
Duty Cycle
The actuator may run continuously at temperatures below 104° F for up to 15 minutes. After that 15 minutes, the actuators
may run up to 75% duty cycle (between each full cycle), the actuator must rest for 1/3 of the 90 degree cycle time.
NOTE: At 50 Hz, the duty cycle is ~60% at 104° F (40°C).
Voltage
115 VAC: 103.5 to 126.5 VAC, 60 Hz
230 VAC: 207 to 253 VAC, 60 Hz
Limit Switches
(2) Single pole, double throw switches rated for 11A 1/2HP 250 VAC, CSA certied, fuse protected.
Two standard switches are used for end of travel control, and for pilot or position indication at terminal 5 and terminal 6.
Indication outputs are protected by 0.25 AMP permanent auto reset polyfuses – reset time approximately 3 mins.
Motor Split phase, capacitor driven motor with Class B or better insulation; sub-fractional horsepower
Lubrication Permanently lubricated gear train and bearings
Gear Train Hardened steel spur gears
Approximate Weight
17 lbs (8 kg) for sizes up to 600 lb•in (50 lb•ft; 68 Nm)
31 lbs (14 kg) for sizes 1000 lb•in (83 lb•ft; 113 Nm) and above
Enclosure Die cast aluminum
IMO 11/17
12 IMO-I2500 EN
