Metso VALVCON V-Series User Manual

3/4 NPT Standard
1/2 NPT with Bushing
6.000
6.1
3.1
4.1
5.8
1.7
*12.8
11.1
10.3
Optional
Handwheel
Shown
10.8
9.8
7.5
4.6
3.3
Female Square Drive
Mounting Flange, ISO 5211
All Dimensions in inches unless otherwise
0.787 (20mm)
TO REMOVE COVER REQUIRES AN ADDITIONAL 5.75"
LV-SERIES
1.50 (38.1mm)
stated
LV-Series
*11.7 WITHOUT HANDWHEEL
F07/F10
Female Keyed Drive
Actuator Size Drive Option Drive Type Drive Size Depth
1000-3000 lb-in (83-250 lb-ft; 113-339 Nm) Standard Square 1.000 (25mm) 1.20 (30.5mm)
1000 lb-in (83 lb-ft; 113 Nm) Option "I"Square0.748 (19mm) 1.20 (30.5mm)
1500-3000 lb-in (125-250 lb-ft; 169-339 Nm)Option "I"Square0.866 (22mm) 1.20 (30.5mm)
1000-3000 lb-in (83-250 lb-ft; 113-339 Nm) Option "Y"Keyed
Approximate Weight 31 lb / 14 kg
4.6
0.75" MIN.
ON
4 X M8-1.25
2.756" B. C. ON
4 X M10-1.5
0.75" MIN.
SEE TABLE
20 mm
22.4 mm
4.8 mm
4.016" B. C.
V-Series
Actuator SizeDrive Option Drive Type Drive Size Depth
150-600 lb-in (12-50 lb-ft; 17-68 Nm) Standard Square 0.750 (19mm) 0.90 (22.9mm)
150-600 lb-in (12-50 lb-ft; 17-68 Nm) Option “I”Square0.551 (14mm) 0.90 (22.9mm)
150-600 lb-in (12-50 lb-ft; 17-68 Nm) Option ”Y” Keyed 0.591 (15mm) 1.40 (35.6mm)
V-SERIES
Figure 8
6.1 Dimensions
IMO 11/17
IMO-I2500 EN 13
