HygroCal100 User’s Manual
Michell Instruments
5
INSTALLATION
Top Panel
1
2
3
Figure 2 Top Panel
1 Saturator reservoir
Contains a diffuser and distilled water used to humidify the
air in the chamber (see Section 4.2 for instructions on how
to refi ll the saturator).
2 Probe ports
Used to mount probes under test into the chamber (see
Section 2.5.1 for instructions on how to install port adaptors
and probes).
3 Desiccant reservoir
Contains desiccant used to dry the air in the chamber (see
Section 4.1 for instructions on how to replace desiccant).
