Figure 17
Program Calibration Routine Screen
The table provided in the Calibration Routine Screen allows a series of relative humidity
points to be generated for set time periods without intervention by the user.
Each row of the table defi nes a calibration point, with fi elds to enter the desired relative
humidity value and the length of time the chamber should spend maintaining this
humidity.
Once this period of time has elapsed, the chamber will move to the conditions on the
next row. There can be a maximum of 10 calibration points in the routine.
NOTE: The 'Duration' only starts when the chamber has stabilized at the
desired condition.
To initiate the calibration routine, touch the
Start button.
At this point, if logging is not in progress, then a prompt will appear to confi rm whether
or not logging is required.
If
NO is selected, then the program will start and the display will return to the Main
Screen.
If
YES is selected, then the Logging Screen will be displayed. Once data logging has
been initiated the program will run.
