HygroCal100 User’s Manual
14
97500 Issue 3, January 2018
OPERATION
3.4.1 Current Set Point
The target relative humidity level can be changed by pressing the Set Point pane in the
top left of the main screen. This is only possible when Calibration Settings ->
Mode is
set to
Manual.
Set Point
11:
7
4
70.0%
1
0
8
5
2
.
9
6
3
C
Figure 13
Set Point Entry Screen
3.4.2 Probe Selection
The probe selection pane on the Main Screen can be confi gured to show the relative
humidity and temperature readings of any of the connected probes.
To cycle through the connected probes, touch the left or right arrow keys on either side
of the probe number indication.
3.4.3 Operational Status Display
The Operational Status Display includes the following:
Chamber
Indicates the operational condition of the chamber.
Options: RESPONDING, STABILIZING, STABLE or OFF
Mode
Indicates the operating mode of the chamber.
Options: MANUAL, AUTO or STANDBY
Next Point
When the conditions in the chamber are stable this will indicate the
time remaining until the next set point.
