Functional Principle, Technical Data
optoCONTROL CLS-K
Model CLS-K- 10 11 20 30 31 40 50 51
Switching current
5 -
100 mA
50 μA -
2 A
5 -
100 mA
5 -
100 mA
50 μA -
2 A
5 -
100 mA
5 -
100 mA
Switching power
5 μW -
60 W
125 VA
5 μW -
60 W
125 VA
Switching frequency
max.
4 kHz 4 kHz 60 Hz 4 kHz 4 kHz 60 Hz 4 kHz 4 kHz
Saturation voltage ≤ 2.0 V ≤ 2.0 V ≤ 2.0 V ≤ 2.0 V ≤ 2.0 V ≤ 2.0 V
Pulse stretching
5 - 100 ms
Adjustable with potentiometer
P2
Analog output 0.1 - 5 VDC, output resistance 1 kOhm
Type of connection Line 2 m Screw connectors 1.5 mm
2
(plug-in version on request)
Electromagnetic
compatibility (EMC)
EN 61000-6-3: 2011-09, EN 61000-6-2: 2006-03, EN 61000-4-2: 2009-12, EN
61000-4-3: 2011-04, EN 61000-4-4: 2013-04, EN 61000-4-5: 2007-06, EN 61000-4-
6: 2009-12, EN 61000-4-11: 2005-2, EN 55011: 2011-04
2.5.2 Models CLS-K-60 up to -65
Model CLS-K- 60 61 63 65
Power supply 12 - 30 VDC
Residual ripple
≤ 10 %
Current consumption
~ 70 mA
Switching delay
≤ 500 ms
Switching frequency ≤ 4 kHz
Response time ≤ 120 µs
Temperature drift ≤ (-)0.5 % /K
Reproducibility ≤ 1% at ∆ϑ = 2 K
Hysteresis 4 % of the measuring value range
Analog output 0 - 20 mA 0 - 10 VDC 0 - 20 mA 4 - 20 mA
Current output Load ≤ 600 Ω
Switching output Transistor 2 x NPN O.C.
