Operation and Setting
optoCONTROL CLS-K
6.2.3 Additional Settings with Options
- Light or dark switching is selectable with switch S2, see Fig. 20.
- Pulse stretching is selectable with the potentiometer P2 by turning clockwise, see Fig. 20.
Switch S2
Potentiometer P2
= light
= dark
Fig. 20 Potentiometer P2 and switch S2
