Electrical Connections
optoCONTROL CLS-K
5.2 Pin Assignment Models CLS-K-60 up to -65
CLS-K-60/-63/-65 CLS-K-61
3
1
2
3
4
5
6
GND
12 - 30 VDC
Current output
NPN output O.C.
NPN output O.C.
1
2
brown
pink
green
yellow
gray
white
GND
12 - 30 VDC
Analog output +
Analog output GND
NPN output O.C.
NPN output O.C.
1
2
Fig. 11 Pin assignment models CLS-K-60 up to -65
1) Dark switching
2) Light switching
3) No terminal block available
