Page 17
Mounting
optoCONTROL CLS-K
4.1 Fiber Optics
Various fiber optics are available for the optoCONTROL CLS-K, siehe Kap. A 1. It is possible to use an optimal
probe even in confined conditions.
The fiber optics is inserted into the provided adapter and locked with the cap nut, see Chap. 4.2.
i
The male connector of fiber optics is coded on the amplifier side and must not be plugged in by force!
Treat the fiber optics carefully. Do not fall below the bending radius of the fiber optics (3 x the outside diame-
ter).
> Breakage of the fiber optics fibers
> Impairment of the switching behaviors
Do not touch the front surface of the probe.
> Impairment of functionality by contamination
Do not install more fiber optics probes directly next to each other.
> Mutual interference
Do not use cable ties in order to fasten the PVC coating.
> Breakage of the fiber optics fibers
NOTICE
