MICRO-EPSILON optoCONTROL CLS-K-10 User Manual

Page 30
Operation and Setting
optoCONTROL CLS-K
1 Turn the potentiometer P1 (sensitivity) clockwise, until the LED changes from green to red (max.
15 turns), see Fig. 18.
Add one turn for the function reserve.
In the case of a large scanning range set S1 switch to Far.
i
The analog signal can be used for finding the optimal setting.
2 Set the requested lower point onto the characteristic line to 0 V using the potentiometer P3.
The value can be reduced by a maximum of 3 V.
3 Set the requested upper point onto the characteristic line to 10 V using the potentiometer P2.
There is a maximum of a quadrupling of the original voltage possible.
4 Repeat process 1 and 2 to optimize the setting.
Back to factory setting:
Push the switch S2 in position 1.
Set the potentiometer P1 to the left (max. 10 turns).
Push the switch S2 in position 2.
Set voltage with potentiometer P3 to 0 V.
Push the switch S2 in position 1.
Set analog voltage with potentiometer P1 to 5 V.
Push the switch S2 in position 2.
Set voltage with potentiometer P2 to 10 V.
