ZLR964222L Line Module User Guide
7
Microsemi Corporation Confidential and Proprietary
2.0 Quick Start Guide
2.1 Required Materials
The following materials will be required to set up the ZLR964222L line module system:
• Le71HK0004 Telephony Applications Platform (ZTAP) Kit with file system P1.14.0 or later (available from
Microsemi’s web site, OPN Le71SDKZTAP);
• Software tools downloaded from the Microsemi web site, including MiToolkit (OPN Le71SDKTK), release
P1.8.0 or later, and Profile Wizard (OPN Le71SDKPRO), release P2.4.0 or later;
• ZLR964222L line module;
• Two analog telephone sets; and
• Two RJ-11 telephone cords.
Refer to Ta b l e 1 for a listing of the essential MiToolkit applications.
Application
Operating
Functions
Description
VP-Script ZTAP Control ZTAP software image update; Tcl script editing and execution; console and
terminal communication
Mini-PBX Main Window /
Stand-Alone
Visual PBX
Discovers modules and assigns extension numbers and termination types
(FXS or FXO) for each hardware port; Initializes the Call Control application
with the profiles parameters found on the Module ID (MID) for each of the
installed modules; Displays real-time status and VP-API-II line states for all
extensions; Enables calling from any FXS into any other FXS or an FXO port.
Profile
Parameter
Loading
By clicking on any extension displayed on the Mini-PBX main window, Profile
Wizard-generated files may be loaded and applied to the port associated with
that extension. Profiles include AC and DC coefficients, Ringing parameters,
FXO / Dialing parameters, etc.
Half Channel
Setup and
Testing
By clicking on any extension displayed on the Mini-PBX main window, the
following half-channel functions are available: a) Manual line state control, b)
PCM time slot assignment, and c) RX and TX gain adjustment. These
functions enable AC and DC functional testing by placing the channel into one
of the VP-API-II system states and connecting the PCM highway to the E1/T1
interface on the ZTAP platform.
Line Testing Clicking on any FXS extension displayed on the Mini-PBX main window and
selecting the Line Testing tab provides access to VeriVoice tests. Tests such
as line voltage, receiver off-hook, resistive faults, and ringer equivalence
number (REN) may be run on that port.
VP-API-II Line
Debug
By clicking on the Terminal menu item, a terminal application is launched
allowing the user to type commands and view VP-API-II run-time debug
messages. The VP-API-II function VpSetOption() with
VP_OPTION_ID_DEBUG_SELECT is used to enable debug messages.
Table 1 - Essential MiToolkit Applications
