5 Instrument
REMOVE CHAMBER AND PLUNGER
Do not attempt to remove the chamber and plunger while the analyzer is operating.
While removing the chamber/plunger assembly from the analyzer, check to see if either
end has become loose during analysis. If either end is not securely attached to the man-
drel, analysis data may be inaccurate. Ensure that the chamber and plunger are
securely attached to the analyzer and restart the analysis.
1. Unscrew the plunger from the right mandrel by turning the coupling on the mandrel toward
you. Continue turning/unscrewing until the plunger is free of the mandrel. Hold the plunger to
stabilize it while turning the coupling.
2. Push the plunger a small distance into the chamber.
3. Unscrew the chamber from the left mandrel (in the center of the large disc) by turning the
chamber toward you. Hold the disc to stabilize it while unscrewing the chamber.
4. When the chamber is free, remove it from the mandrel.
INSERT PLUNGER
The seal end of each plunger fits snugly into the corresponding chamber. The plunger slides slowly
but smoothly inside the chamber. After loading the chamber, slide the seal end of the plunger about a
third of the way into the chamber.
5 - 4
GeoPyc 1365 Operator Manual
136-42800-01 (Rev -) — Dec 2016
