6 Maintenance
Field or Button
Description
Calibration. Select the Allow force calibration option to allow force
calibration.
Stored Information. Displays the disk space used by the application
and associated records.
Tap the applicable button to delete or reset options:
l Delete All Records
l Delete All SOPs
l Reset the Force Calibration to Nominal
l Set Chamber Information to Defaults
Network Settings. Select if the analyzer uses DHCP or a Static
IPaddress.
Agitation Amplitude
[button]
Select if the agitation should be set to low or high.
Build date
Displays the software version and release date.
Chambers
Settings for the chamber's diameter, zero depth, conversion factor,
and consolidation force.
Current time [textbox]
By default, the application uses UTC to set the current date and time,
however if using NTP: enable the NTP option, complete the Current
time field (yyyy-mm-dd-hh:mm:ss format). Also select the timezone
using the Timezone drop-down box.
Displacement cycles
Total number of cycles performed since the force calibration.
Force Calibration
The calibration slope as a percentage of the nominal slope.
Force Unit [button]
Select if the force should be measured as a newton measurement or
as counts.
IPaddress
IPaddress of the analyzer.
Location [textbox]
Location of the analyzer.
Maintenance Fields and Buttons Table (continued)
