24 Port Gigabit Ethernet PoE Switch – User Manual Page 15 of 72

________________________________________________________________________

2-2. Typical Applications

The switch implements 24 Gigabit Ethernet TP ports with auto MDIX and four slots

for the removable SFP modules. For more details on the specification of the switch,

please refer to Appendix A.

The switch is suitable for the following applications.

Central site/remote site application is used in carrier or ISP (See Fig. 2-10)

Peer-to-peer application is used in two remote offices (See Fig. 2-11)

Office network(See Fig. 2-12)

Fig. 2-10 Network Connection between Remote Site and Central Side

Fig. 2-10 is a system wide basic reference connection diagram. This diagram

demonstrates how the switch connects with other network devices and hosts.

Central Site
