Microsens MS400863M User Manual

24 Port Gigabit Ethernet PoE Switch – User Manual Page 2 of 72
________________________________________________________________________
©2014 MICROSENS GmbH & Co. KG – Hamm/Germany www.microsens.com
1-2. Checklist
Before you start installing the switch, verify that the package contains the following:
24 Port Gigabit Ethernet Switch with PoE and WEB management
Mounting Accessory (for 19” Rack Shelf)
This User's Manual in CD-ROM
AC Power Cord
Please notify your sales representative immediately if any of the aforementioned items is
missing or damaged.
1-3. Features
This switch provides the comprehensive features listed below for users to perform
system network administration and efficiently and securely serve your network.
Hardware
20 10/100/1000Mbps Auto-negotiation Gigabit Ethernet TP ports
4 dual media ports (10/100/1000Mbps TP or 1000Mbps SFP with
auto sense)
512KB on-chip frame buffer
370 watts for PoE
Rack mounting option
Jumbo frame support 9KB
Power Saving with "ActiPHY Power Management" and "Perfect
Reach Power Management" techniques.
Programmable classifier for QoS (Layer 2 / Layer 3)
8k MAC address and support and 24 different VLAN IDs out of
1~4094
Broadcast Storm Control
Full-duplex flow control (IEEE802.3x) and half-duplex backpressure
Extensive front-panel diagnostic LEDs: System, Power; TP Port1-
24: LINK/ACT, PoE, 10/100/1000Mbps; SFP Port 21,22,23,24:
(LINK/ACT)
Management
Supports concisely the status of port and easily port configuration
Supports per port traffic monitoring counters
Supports port mirror function
Supports the static trunk function
Supports RSTP according to 802.1w and STP (802.1d)
Supports 802.1Q VLAN
Supports user management and limits one user to login
Maximal packet length can be up to 9600 bytes for jumbo frame
application
Supports Broadcasting Suppression to avoid network suspended or
crashed
Supports to send the trap event while monitored events happened
Supports default configuration which can be restored to overwrite
the current configuration which is working on via Web UI and reset
button of the switch
Supports on-line plug/unplug SFP modules
Supports Quality of Service (QoS) for real time applications based
on the information taken from Layer 2 to Layer 3.
Built-in web-based management instead of using CLI interface,
providing a more convenient GUI for the user
